Vought A-7C Corsair II

The Corsair II was designed as a lightweight attack aircraft to supplement and later replace the Douglas A-4 Skyhawk. In addition to service in our Navy, Corsair II's were flown by our Air Force, Air National Guard, and several other nations.



  • a71
  • a75
  • a7c 2
  • EWMslideshow 017
  • IMAGE_1506
  • IMG_2619
  • IMG_7254
  • IMG_9478
  • IMG_9695
  • IMG_9703
  • IMG_9734
  • PC250027
a711 a752 a7c 23 EWMslideshow 0174 IMAGE_15065 IMG_26196 IMG_72547 IMG_94788 IMG_96959 IMG_970310 IMG_973411 PC25002712

Specifications

Manufacturer: Vought Aeronautics Division of Ling-Temco-Vought
Year/Model: 1967 A-7C
S/N: 156739
Tail Number: 156739
Power Plant: 11,350 lb Pratt & Whitney TF30-P6 turbofan
Wingspan: 38 feet 9 inches; Folded: 23 feet 8 inches
Length: 46 feet 1 inch
Height: 16 feet 3 inches
Gross Weight: 42,000 pounds
Maximum Speed: 691 mph
Maximum Range: 2,280 - 3,070 statute miles
Service Ceiling: 32,500 feet
Crew: 1
Status: Static Display, On loan
Owner: US Naval Air Museum, Pensacola, FLA

A-7C in Flight


A7C

Some Assembly Required. Our A7 arrived at Estrella Warbird Museum in July, 1998, after being trucked in from NAS China Lake. It has since been fully restored to static display.

History

The Ling· Temco-Vought A-7 production line started on 19 March 1964 and continued until September 1984; 1,545 were built. Its first flight, powered by a Pratt & Whitney TF3O-P-6 turbofan engine, was on 27 September 1965. Navy Preliminary Evaluations were underway in January 1966. Test programs were accomplished with wartime urgency, and the first fleet delivery (VA-174) was on 14 October 1966.

Early A-7s were powered by the Pratt & Whitney TF30-P-408. Later versions were powered by the Allison TF41-A-2. The Corsair II was used extensively in Vietnam. The last two Navy squadrons equipped with A-7s saw action during operation Desert Storm.

This aircraft is also known as the LTV A-7 Corsair II due to changes in company ownership. This capable aircraft acquired the nickname SLUF for Short Little Ugly Fellow(or words to that effect). Retirement of the last two Navy A-7 aircraft fleet operational squadrons (VA-46 and VA-72) was in May 1991.

A total of 535 A-7Es were built, the last one being delivered in 1983. At its peak in the mid 1980s, some 22 Navy attack squadrons were using the A-7E. The last of the A-7A squadrons were disestablished and the last of the A-7Bs were transferred to reserve squadrons by 1977.
